4.8.2 TRUCK
When attaching the machine to a truck, follow
this procedure:
1. Clear the area of bystanders, especially
small children.
2. Make sure there is enough room and clear-
ance to safely back up to the machine.
3. Slowly back the truck until the hitch and ball
are aligned.
a. Install the drawbar pin through the
hitch.
b. Install the retainer through the drawbar
pin.
4. Attach the safety chain securely to the truck
frame to prevent unexpected separation.
Fig. 25 ALIGNED
Pin
Retainer
Fig. 26 DRAWBAR PIN
Fig. 27 SAFETY CHAIN
